DIP Switch
Turn ON DIP swith 2
Enable Receiver
- [Installer Code] [#]
- [395] [#]
- [2] [*]
- [960] [#]
Learn Keyfobs
- [Master Code] [1] [#]
- User 1 to 22 – [301 ….. 322] [#] [#]
- Press any button on Remote, wait for beep x2
- [#] [#] to finish
Program Relay 1 & 2
- Press the Learn SW until the LED goes off (approx 1 sec) and Release.
- Select the relay to be programmed by pressing the LEARN SW once for each output. (e.g. Press TWICE for Relay 2)
- Having selected the relay, press the desired button on the Keyfob to be learned to the relay
- Repeat for each button required
Note
- A maximum of 12 keyfob’s per receiver.
- The TR800 will exit learn mode after 25 secs or Keyfob is successfully learned
